Residual liquid dumping conveying system: In order to improve the cleanliness of the waste iron drum and speed up the cleaning time, it is necessary to remove the residual substances in the drum as much as possible before entering the cleaning process. The residual substances in the drum can be recycled, saving the cleaning cost of the drum. The residual substances in the drum include fluid residue and viscous residue. This material dumping conveyor is a special equipment for dumping the viscous residue in the drum during the conveying process.

Labels removing conveyor : Used 2 0 0 L iron drums are definitely sticky with labels and other adhesive materials. In order to reuse the old iron drums, the external surface of the old iron drums needs to be removed before entering the cleaning process. This manual label removal conveyor is used for manually re-moving the labels on the external surface of the old iron drums on this conveyor.

Reshape machine for the edge : The barrel edge of the iron barrel is prone to deformation and ovality during transportation , handling, and use, and it is also prone to crack and leakage. Therefore , it is necessary to reshape the barrel edge of the old iron barrel. This fully au- tomatic barrel mouth reshaping machine for iron barrels is used to make the barrel mouth of the old iron barrel round and repair the leaking part of the barrel edge . It is the best equipment to solve the problem of barrel edge leakage.

Reshape machine for the drum :

The iron barrel will inevitably undergo severe deformation, ovality, and unevenness during transportation, handling, and use. Therefore, it is necessary to reshape and repair the body of the old iron barrel. This fully automatic closed iron barrel reshaping machine is used to make the oval and uneven parts of the old closed iron barrel round and smooth the barrel surface. It has a high degree of au- tomation and can achieve automatic feeding, clamping, and inflation to realize the mechanical reshaping of the iron barrel body. It is an essential key equipment for refurbishing old iron barrels.
The machine is equipped with a fully automatic iron barrel conveying device, which automatically sends the iron barrel onto and off the fixed rotating pallet. The fixed rotating pallet rotates the inflated iron barrel, and the movable rotating pressure plate automatically clamps the iron barrel, so that the iron barrel is firmly locked between the fixed rotating pallet and the movable rotating pressure plate. The automatic inflation mechanism automatically inflates and pressurizes the iron barrel. When the pressure inside the iron barrel balances with the external shaping pressure,
the two sets of pneumatic pressure roller mechanisms of the shaping pressure roller mechanism flatten and shape the inflated iron barrel , achieving the purpose of barrel shaping.
